Professional Production Customized Shaker Screen Vibrating Screen Medicine
Description
The test sieve model is divided into two type according to the sieve diameter. It is designed with panel control of start switch and timer, which is easy to operate and convenient to use.
The standard test sieve models have corresponding fixtures. It can be installed with 1 to 8 layers of sieves, and multiple samples can be decomposed for the materials tested. With integrated circuit control, the amplitude, frequency and vibration mode can be adjusted.
Low noise, light weight and high precision make our test sieves suitable for inspection and analysis of particle, powder, slurry and so on.
Specification
1. Construction Material: carbon steel/ stainless steel;
2. Diameter of placing test sieve: 100mm/200mm/300mm.
Features
1. New type of special power generator to produce multivariate and high frequency vibration to screen samples with high efficiency.
2. Standard sieve, to ensure the accuracy of sample analysis
3. Electronic delay device, to set equivalent screening time among the same material to ensure the uniformity of the sample analysis.
4. Reduce the experimental error to the minimum, and then to make an accurate judgment of the quality of the product.
Apply in Industry
The testing sieve is widely used in testing analysis of chemical, pharmaceutical, food, building materials, powder metallurgy, and material in the processing process of the sewage and waste water from environmental protection industry.
Working Principle
The sieving machine can place 1-8 layers of test sieves so that the materials in the test sieves can be effectively screened, graded and filtered. Because the screen surface can vibrate up and down at high frequency, so that the material can be thrown out from the mesh, the material rarely sticks to the mesh, which improves the screening efficiency of the ultra-fine material.
Technical Parameters
| No. | Name | Units | Size |
| 1 | Sieve diameter | mm | Φ200. Φ100. Φ75(Customized according to user requirements) |
| 2 | Sieve layer | Layer | 1-3 |
| 3 | Φ200 test sieve | Set | Can provide a full range when user buy(0.005-150mm) |
| 4 | Shaking distance | mm | 25 |
| 5 | Motor | Power /Voltage | W/V | 90/220 |
| Speed | R/min | 0-290(Arbitrary adjustable) |
| 6 | Dimensions | mm | Length × width × height
350:350:360 |
| 7 | Ultrasonic Frequency | HZ | 40K |
| 8 | Screen Machine Weight | kg | 40 |
| 9 | Trajectory | | A circular motion, close to circular motion |
Note: can increase the negative pressure devices for users, Minimum screen to 5 microns.
Packing
Our Advantage
Our company is a ISO9001:2000 certification enterprise, we cooperate with large domestic companies and some scientific research units. The follow picture is our long term cooperator.
Our Service
1. We Provide video installation instructions;
2. We offer 24-hour online consulting service;
3. 20 years production experience to ensure quality;
4. We have thorough data to ensure the quality;
5. We provide detailed instruction an product information;
6. We provide 12 months quality warranty;
7. We have professional engineer team ensure to provide the most professional equipment.
If you want to get more information of product, please contact us!
